Header / Manifold 2.3L Mustang SVO Thunderbird XR4Ti

**Product Features:**

Rev up your 84-86 Mustang SVO or Thunderbird 2.3L turbocharged engine with our high-performance Turbo Manifold. This manifold is engineered to deliver top-end power and superior exhaust flow, enhancing your turbo performance. Here's why it's a standout choice:

- **Versatile Fitment:** Compatible with stock Garrett T3 turbo, T3/T4 hybrid turbo, and 87-88 IHI turbo.
- **Top Mount Position:** Reorients the turbo to a top mount position, making removal and installation a breeze.
- **Optimized Design:** The tubular manifold design ensures better exhaust flow for maximum power output.
- **Equal Length Runners:** Enhance exhaust reversion and turbo performance, creating balanced performance.
- **Durable Construction:** Crafted from fully mandrel-bent 16-gauge 304 stainless steel tubes for exceptional strength.
- **Robust Flanges:** Head flanges are laser-cut from 7/16-inch thick steel plates, flattened for a precise, leak-free seal, and chrome-plated for corrosion resistance.
- **TIG Welded Joints:** All joints are TIG welded for crack and wear resistance.
- **Polished Finish:** A polished surface offers added protection against rust.
- **Track/Off-Road Use:** Designed for track and off-road use.

**Tech Specs:**

- **Manifold Type:** Turbo Manifold
- **Runner Diameter:** 1-5/8 in. (42mm)
- **Runner Layout:** Equal Length
- **Turbo Fitment:** T3, T3/T4 Hybrid
- **Turbo Mount Position:** Top Mount
- **Wastegate Fitment:** 38mm (2-bolt)
- **Head Flange Thickness:** 7/16 in. (11.5mm)
- **Pipe Thickness:** 16 gauge (1.5mm)
- **Material:** 304 Stainless Steel
- **Finish:** Polished
- **For track/off-road use only**
- **No instructions provided; professional install recommended**

**IMPORTANT:**

- **NOT a direct replacement to OE manifold**
- **Does NOT provide EGR**
- **Changes location of the turbo**
- **Using an external wastegate with this manifold will require a dump tube with a flex section to route the wastegate into the downpipe.**

Elevate your vehicle's turbocharged performance with our Turbo Manifold, specially designed to maximize power and optimize exhaust flow. Upgrade your engine today!
